Hot wire air velocity probe with flip up telescopic sensor wand. Use with free TPI View App to display air velocity and air flow.

SP565 Thermal Anemometer Smart Probe
SP565 Thermal Anemometer Smart Probe
SP565 Thermal Anemometer Smart Probe
SP565 Thermal Anemometer Smart Probe
SP565 Thermal Anemometer Smart Probe
SP565 Thermal Anemometer Smart Probe
SP565 Thermal Anemometer Smart ProbeSP565 Thermal Anemometer Smart ProbeSP565 Thermal Anemometer Smart ProbeSP565 Thermal Anemometer Smart ProbeSP565 Thermal Anemometer Smart Probe
  • Measure air velocity and temperature simultaneously
  • Communicate with Android & iOS Smart Phones using
    Bluetooth LE and TPI Apps
  • Record minimum, maximum & average
  • Multiple measuring units: m/s, km/h, ft/min, knots, mile/h

Ranges:

  • Air Velocity: 40 to 3900 fpm; 0.2 to 20 m/s
  • Temperature: -5°F to 175°F (-20°C to 80°C)

TPI View App
Use the TPI View App to display real time readings in numeric and graph format.  Job Management allows you to create multiple JOBS and attach multiple REPORTS to each Job! Give each report a different reference/name; save to an existing JOB or create a NEW one!

Where to Buy TPI Products

TPI View App
Use with TPI Smart Devices

Use your smartphone to interact with TPI’s Smart Devices. Job Management allows you to create multiple JOBS and attach multiple REPORTS to each Job! Give each report a different reference/name; save to an existing JOB or create a NEW one!

  • Air duct analysis to balance commercial and residential HVAC systems
  • Fume hoods
  • Floor registers
  • Exhaust grills

Click to view or download product PDFs

SP565 Data Sheet

SP565 Smart Probe Air Velocity Meter Specifications
Air Velocity Measurement Range-40 ft/min to 3900 ft/min (0.2 m/s to 20 m/s)
Air Velocity Accuracy+/- (5% of rdg + 10 digits) or +/- (1% FS + 10 digits)
Resolution1 ft/min / 0.01 m/s
Temperature Measurement Range-4⁰F to 140⁰F (-20⁰C to 60⁰C)
Temperature Accuracy+/- 1⁰F (0.5⁰C) (32⁰F to 113⁰F / 0⁰C to 45⁰C )
+/- 2⁰F (1⁰C) (113⁰F (45⁰C)
Units of Measurem/s, km/s, ft/min, miles/hr, knots/hr
Operating Temperature-4⁰F to 122⁰F (-20⁰C to 50⁰C)
CommunicationBluetooth version 4.2 (Use with TPI Smart Probe App)
Battery typeAAA x 3 (4.5V)
Battery Life60 hours typical
CFM CalculationPerformed via TPI Smart Probe App
